CITAI: Un vistaso al Interior

Presentación del tema: "CITAI: Un vistaso al Interior"— Transcripción de la presentación:

1 CITAI: Un vistaso al Interior
Fernando Pérez Muñoz marzo 2007

2 Area de Oficinas Salón de Conferencias Profesor Profesor Profesor
Administrador Profesor Personal Administrativo Profesor Oficina Ayudante o Sala Privada Recepción Director Almacén y Archivos

3 Inventario & Equipo Area de Oficinas
Descripción Cantidad Costo Unitario Total Escritorio en “L” 6’ * 7’ 9 $1,171 $10,539 Gavetero bajo escritorio 11 $214 $2,354 Gavetero “locker” 7 $300 $2,100 Silla ergonómica $260 $2,340 Sillas visitante 23 $55 $1,265 Mesa redonda 42” 3 $182 $549 Librero 8 $193 $1,544 Archivos verticales 21 $225 $4,725 Mesa rectangular 30” * 60” 4 $175 $700

4 Cocina Experimental Horno de microondas Estación para lavado de manos
Closet Horno Pizza & Pan Gabinete/Counter para sensorial Nevera Mesa Stainless Steel (3’ * 8’) Hunter Lab Texture Analyzer Estación para lavado de manos Lavaplatos (bajo counter) Almacén de enseres eléctricos Estufa de 6 hornillas con horno Mesa de trabajo Fregadero de 3 compartimientos Estufa de 4 hornillas con horno & plancha Horno de gas para pan y pizza

5 Inventario & Equipo Cocina Experimental & Catado
Descripción Cantidad Costo Unitario Total Mesa Stainless Steel 36”*96” 1 $1,826 Nevera con congelador 2 $7,200 $14,400 Estufa 6 hornillas con horno $5,300 Estufa 4 hornillas con horno $3,800 Estación lavamanos $650 Fregadero 3 comp. (6 pies) $1,300 Horno para pan y pizza $18,580 Gabinete para sensorial (abajo) 13 pies $70 $910 Gabinete cocina (abajo/arriba) 25 pies $125 $3,125 Lavaplatos $4,200

6 Inventario & Equipo Cocina Experimental & Catado
Descripción Cantidad Costo Unitario Total Silla ergonómica 6 $260 $1,560 Closet 8 ft2 $125 $1,000 Counter para área de catado 13 pies $40 $520 Mezcladora 1 $570 Procesador de alimentos $165 Licuadora $400 Balanza 2 $200 Horno Microondas $2,000 Colorímetro $10,000 Texture Analyzer $23,000

7 Inventario & Equipo Cocina Experimental & Catado
Descripción Cantidad Costo Unitario Total Computadoras para sensorial 4 $1,000 $4,000 Programamdo Compusense 5 $3,684 $14,736

8 Microbiología de Alimentos
Balanzas Bax Chemical Fume Hood Ultra Freezer Freezer Nevera Autoclave Autoclave Autoclave Autoclave Lavaplatos Spiral Plate Class II Bio safety Destilador de agua Class II Bio safety Plate Counter químicos Almacén Closet Batas Microscopios Incubadoras “Shaker Incubadoras

9 Inventario & Equipo Microbiología de Alimentos
Descripción Cantidad Costo Unitario Total Balanza 2 $739 $1,478 Microscopio 4 $339 $1,356 Sistema Bax 1 $42,000 Spiral Plate $16,050 Plate Counter $150 $300 Incubadoras “Shaker” $6,500 Incubadoras $2620 $10,480 Nevera $7,025 7,025 Ultra Freezer $15,899 Autoclave $10,450 $41,800

10 Inventario & Equipo Microbiología de Alimentos
Descripción Cantidad Costo Unitario Total Destilador de agua 1 6000 Almacén de químicos (4 pies) 2 2000 Campana de extracción 10000 Mesa de trabajo pared (2.5’) 20 pies 150/ft2 Mesa de trabajo isla (4’ * 9’) Sillas ergonómicas 6 $260 $1,560 Balanzas $99 $198 Gabinetes almacenamiento 4 $1,185 $4,740 Lavaplatos $4,200 Freezer $10,025 10,025

11 Química de Alimentos Almacén Nevera Freezer Ultra GC HPLC carro
Flamables Extractor Nevera Freezer Ultra GC HPLC carro Absorción Atómica Mesa de Granito

12 Inventario & Equipo Química de Alimentos
Descripción Cantidad Costo Unitario Total Gabinete para inflamables 1 1,000 Extractor (30”) 6,500 Extractor (78”) 2 12000 Mesa de trabajo isla (4’ * 11’) 150/ft2 Mesa de trabajo pared (2’ * 24’) Carro para manejo de material 200 Almacén químicos sólidos (4’*7’) 4000 Silla ergonómica 6 $260 $1,560 Mesa para GC/HPLC (30” * 36”) 1000 Mueble con lavamano (24”*42”)

13 Inventario & Equipo Química de Alimentos
Descripción Cantidad Costo Unitario Total Nevera 2 $7,025 $14,050 Freezer 1 $10,025 10,025 Ultra-freezer $15,899 Campana de Extracción 6000 Fat Analysis System $18,000 Fiber Analysis System $20,000 Mesa de granito 5000 Protein Analyzer 25000 Ash furnace 10000

14 Area de Fermentación Balanza analítica en mesa de granito Metro pH
Autoclave Nevera Campana Extracción Metro pH Plato de agitación Autoclave (2) Platos calientes Fermentador (2) Incubadoras (3) Almacén envaces de fermentación Baño agua caliente (2) Incubadora “Shaker”

15 Inventario & Equipo Area de Fermentación
Descripción Cantidad Costo Unitario Total Mesa de granito (18” * 24”) 1 5000 Mesa de trabajo isla (9’ * 4’) 150/ft2 Mesa de trabajo pared (2.5’) 33 Gabinetes 14 pies 100/ft Tablillero (24” * 5’ * 6’) 1500 Metro pH $1,200 Plato de agitación $1,500 Platos calientes 2 $400 $800 Balanza analítica $3,000 Silla ergonómica 6 $260 $1,560

16 Inventario & Equipo Area de Fermentación
Descripción Cantidad Costo Unitario Total Incubadora “Shaker” 1 $9,500 $28,500 Neveras 2 $7,200 $14,400 Fermentadores con controles $24,500 $49,000 Incubadoras $3,000 $6,000 Refractómetro 3 $100 $300 Envases de fermentación (5 gal) 10 $125 $1,250 Baño de agua $1,500 Autoclave $10,450 Biological Safety Cabinet $11,000 Vortex

17 Planta de Procesamiento
Procesamiento a Alta Presión Productos sólidos a base de farinaceos y frutas Procesamiento de Jugos y líquidos Area de Destilación Ahumador Carne Oficina y Referencia Area de Secado y Cocción

18 Planta de Procesamiento
Esterilizador de alta presión Columna Destilación Controller House & Smoke UHT HTST Asceptic Pack Microwave Workatation Homo- genizer Desk Books File Spares Chiller Ultra Filtration Spray Dryer Drum Scrape Surface Freeze Vacuum Kettle Extruder Incruster Retort Steam Canner Staging Area Mixer

19 Inventario & Equipo Planta de Procesamiento
Descripción Cantidad Costo Unitario Total UHT/HTST unit 1 $70,000 Aseptic packaging Unit $85,000 Laboratory Steam Generator $25,000 Reverse Osmosis/UltrafiltrationUnit $55,000 Laboratory Process Chiller $8,000 Pressure Homogenizer $15,000 Extruder $95,000 Vacuum Mix Kettle $10,000 Pilot Size Spray Dryer $32,000 Incruster $72,000

20 Inventario & Equipo Planta de Procesamiento
Descripción Cantidad Costo Unitario Total Drum Dryer 1 $100,000 High Pressure Processing System $625,000 Planetary Mixer 2 $17,000 Swept Surface Cooker $19,000 Vacuum Packaging $22,000 Microwave Workstation $26,000 Columna de destilación 10000 SmokeHouse $25,000 Processing Kettle 20000 Canner

21 Inventario & Equipo Planta de Procesamiento
Descripción Cantidad Costo Unitario Total Escritorio en “L” 6’ * 7’ 1 $1,171 Gavetero bajo escritorio 2 $214 Gavetero “locker” $300 Silla ergonómica $260 Librero $193 Archivos verticales $225 Gabiente para repuestos 4 $1,000 $4,000 Caja de herramientas surtida $5,000

22 Productos Cárnicos Acceso a la Nevera Vacuum Tumbler Vacuum Packer
Anaquel Pickle Injector & Brine Pump Stuffer Stuffing Table Deboning Table Bowl Cutter Mixer Nevera Isotherm Freezer Curing Bin Acceso a la Nevera Vacuum Tumbler Scale Vacuum Packer Water Activ WBS Hunter Lab Saw Cutter Carver Press Grinder Patty Maker Warner Bratzler Z Link

23 Inventario & Equipo Productos Cárnicos
Descripción Cantidad Costo Unitario Total Fregadero 1 $1,800 Lavamanos 2 $650 $1,300 Isotherm freezer $11,900 Nevera $950 Mezcladora $7,590 Bowl Cutter $17,495 Curing Bins $780 $1,560 Anaquél 3 $2,186 $6,558 Piston Stuffer $5,195 Stuffing Table $1,495

24 Inventario & Equipo Productos Cárnicos
Descripción Cantidad Costo Unitario Total Pickle Injector & Brine Pump 1 $12,995 Deboning table 3 $1,825 $5,475 Balanza $350 Saw Cutter $2,100 Grindder $995 Z-Linker $1,100 Water Activity Meter $3,500 Hunter Lab Colorimeter $10,000 Warner-Bratzler $1,500

25 Inventario & Equipo Productos Cárnicos
Descripción Cantidad Costo Unitario Total Carver Press 1 $5,500 Vacuum Tumbler $5,200 Vacuum Packer $1,863 Patty Maker $1,800 Wall Cabinets (3 ft) 3 $1,238 $3,714 Laboratory Counters (10 ft) $4,410 Ergonomic chair $260 Stainless Steel Stools 10 $300 $3,000

26 Productos Lácteos O o o O Mesa SS (3’ * 4’) Prensa de Queso Nevera
Tanque Pasteurizador Bomba Mesa SS (3’ * 4’) Prensa de Queso Nevera Mesa Stainless Steel (36” * 8 ‘) Gelato Mantecado Homo- genizador Columna Enfriamiento Fermentador Yogurt Kefir Freezer Ultra O o o O (3’ * 5’) Crema Butter Churn

27 Inventario & Equipo Productos Lácteos
Descripción Cantidad Costo Unitario Total Fregadero 3 compartiminetos 1 $1,800 Mesa stainless steel 36”*96” $1,826 Mesa stainless steel 30”*48” $1,151 Mesa stainless steel 36’*60” $1,413 Tanque pasteurizador 2 $8,050 $16,100 Bomba de circulación $1,000 Descremadora $5,750 Prensa de queso $20,000 Máquina de gelato $17,250 Lavamanos $650 $1,300

28 Inventario & Equipo Productos Lácteos
Descripción Cantidad Costo Unitario Total Máquina de mantecado 1 $17,250 Homogenizadora $23,000 Columna de enfriamiento $12,000 Estufa (4 hornillas + horno) $2,000 Gabinetes cocina (arriba/abajo) 5 pies $5,000 Nevera $7,200 Incubadora de kefir $1,150 Incubadora de yogurt Ultra-freezer $6,900 Ducha de seguridad $500 Silla ergonómica 6 $260 $1,560

29 Información del Equipo Propuesto

30 Sistema de Escritorios
Office Max Unassembled Bush OfficePro Slate Collection Slate Right L-Bow Desk Item # , Style # WC84822 Slate Left L-Bow Desk Item # , Style # WC84833 Slate 36" Desk: Item # , Style # WC8436A Slate 60" Hutch: Item # , Style # WC8461 Slate 36" Storage Hutch Item # , Style # WC84897 Articulating Keyboard Shelf: Item # , Style # AC99801-BLACK

31 Gaveteros OfficeMax Slate 3-Drawer File Slate Vertical Locker
28 5/32"H x 20 5/32"D x 15 1/2"W. Item # , Style # WC8453 Slate Vertical Locker 66 3/8"H x 20 ¾"D x 16 5/8"W Item # , Style # WC84875

32 Mesas Office Max Slate Round Conference Table
29 ¾"H x 41 3/8"D Item # , Style # TB84242 Hon Chrome Legs Utility Table Utility Table, 60"Wx30"Dx29"H, Walnut Item # , Style # HONUTM3060WPCHR

33 Sillas Office Max Ergonomic Task Chair - 8180 Guest Chair
Tilt and swivel capabilities Pneumatic gas height adjustment from 36 ¼"-41 ¼" Height adjustable arms Adjustable back height and angle 5-Star black nylon base with dual wheel casters Seat cushion dimensions: 18 ¼"D x 18 ½"W Guest Chair Sled base Tubular steel frame Back cushion: 21 3/10"W x 13 2/5"H Seat cushion: 19 9/10"D x 20 7/10"W

34 Archivos Office Max HON 462 Series 26-1/2" File CabinetsTilt and swivel capabilities Putty 4-Drawer Letter File Cabinet 52"H x 26 ½"D x 15"W Item # , Style # L46264P,L-PUTTY $203 Putty 4-Drawer Legal File Cabinet 52"H x 26 ½"D x 19"W Item # , Style # L46264CP,L-PUTTY $246

35 Estufa de 6 hornillas GalaSource
Imperial 36" Restaurant Range - IR-6-C 198,000 BTU (6) 12"x12" Burners No Griddle 26 1/2" Convection Oven 36" Restaurant Range - IR-4-G12 167,000 BTU Gas Output (4) 12"x12" 28,000 BTU Anti-Clogging Burners 12" Wide Griddle 26 1/2" Standard Oven

36 Hornos de pizza/pan GalaSource
Gas Deck Oven - Convection Flo - Double Deck- 36" x 34-1/2" by Bakers Pride - 252 60,000 BTUH per deck (120,000 total), natural or LP gas (LP not CE approved) 300° - 650° F (149° - 343° C) throttling thermostat Top & bottom heat control damper Combination gas controls with valve, regulator & pilot safety All stainless steel exteriors Aluminized steel interiors Side or rear gas connections Deck Size: 36" x 34-1/2" Overall Dimensions: 48" x 43" x 64" (W x D x H)

37 Horno de Microondas GalaSource
Amana RC22S 2200W Heavy Duty Commercial Microwave Exterior Dimensions: 18-1/4" H x 19-1/4" W x 26-1/4" D Electrical Requirements: V, 20 Amp, 60 Hz, NEMA 6-20 2200 Watts of power for fast heating 1.0 cubic foot capacity

38 Nevera & Congelador Sears Roebuck
Stainless Steel KitchenAid 29.8 cu. ft. Side-By-Side Refrigerator Sears item # Mfr. model #KSSC48FMS Maximum Depth w/Handle 33-1/2 in. Height w/out Hinge 68-7/8 in. Maximum Height w/Hinge 69-3/4 in. Maximum Width 35-1/2 in. Kilowatt Hrs. per Year 585 Energy Star Compliant Yes

39 Mesa Stainless Steel Gilkore Kramer, Co.
HD Series – Stainless Steel flat top and undershelf WT305FS 30” * 48” $1151 WT366FS 36” * 60” $1413 WT367FS 36” * 72” $1516 WT369FS 36” * 96” $1826 Built for cleanliness and stability. Seamless 14-gauge Type 304 stainless steel work surface and support structure. Shipped knocked down and can be assembled in minutes without tools. All Work Tables are 34" (864mm) high with stationary posts and leveling feet.

40 Fregaderos GalaSource
3 Compartment Sink with 2, 24" Drainboards - 24" x24" x 14" Tubs by SSP Inc. (Model Number S3C24X24224) 18 gauge 304 Stainless Steel top and tubs 14" deep tubs 9" Backsplash Tubs welded together Basket strainers included Galvanized legs with adjustable feet Faucets are not included Tub Size: 24" x 24" x 14" Two 24" Drainboards Depth: 30“ Width: 120" Model #: S3C18X18R18

41 Lavamanos GalaSource 1 Compartment Sink with No Drainboard - 24" x 24" x 14" Tub by SSP Inc. - S1C24X240 18 gauge 304 Stainless Steel top and tubs 14" deep tubs 9" Backsplash Basket strainers included Galvanized legs with adjustable feet Faucets are not included Tub Size: 24" x 24" x 14" No Drainboard Depth: 30“ Width: 29"

42 Lavaplatos GalaSource
Jet Tech High-Temp Undercounter Dishwasher - F-18DP Completely automatic wash and rinse cycles of 150°F (65°C) and 185°F with individual analog temperature gauges Automatic injection of rinse-additive with built-in pump Built-in automatic detergent pump for consistent washing results Performance and capability per hour: ~400 11" plates or up to 600 glasses (rack 5x5) Rating of 24 racks per hour Factory-installed automatic drain pump

43 Equipo de cocina Sears Roebuck
KitchenAid Custom Metallic Series 5 Quart Stand Mixer, Brushed Nickel Sears item # Mfr. model #KSM152PSNK Waring 2-Speed MegaMix™ Specialty Blender, Stainless Steel Sears item # Mfr. model #HBP300 KitchenAid 9-Cup Food Processor Sears item # Mfr. model #KFP740CR

44 Gabinete para químicos inflamables
Cole Palmer EW Flammable Storage Cabinet, Manual-Latching Door, 60 Gallon Capacity 60 gal. Construction 18-gauge steel Self-Closing no Shelves Two Dimensions 31-1/4"W x 65"H x 31-1/4"D Shpg wt 374 lb (170 kg) Shelf depth 28“ Compliance OSHA/NFPA Code 30 specs

45 Campana para área de químicos inflamables
Cole Palmer EW Labconco Fiberglass 30 fume hood, explosion-proof, 1/4 HP blower, no lamp, 115V EW Base storage cabinet for acids for 30" fume hood Blower Explosion proof Size 30" W x 54" H x 30-1/8" D Power 115 V Blower (hp) ¼ Lights None

46 Smoke House Koch Equipment Grand Prize II

47 Vacuum Tumbler Koch Equipment

48 Patty Forming machine Koch Equipment Modelo 330A

49 Piston Stuffer Koch Equipment Modelo SC-50

50 Mesa Portátil Koch Equipment Protégé Mobile Table

51 Z-linker Koch Equipment

52 Stuffing Table Koch Equipment Item # 281015
Dimensions 68" L x 32" W x 37" H Stainless steel construction Adjustable table legs for preferred operator height Operator cut-out Drain

53 Isotherm Freezer Fisher Scientific
Basic -86°C Ultralow-Temperature Freezers Capacity 20 cu ft. Dimensions 36 x 421/4 x 771/2 in. (92 x 107 x 197cm) Catalog # (240 V) # (115V)

54 Mezcladora Koch Equipment

55 Bowl Cutter Koch Equipment

56 Vacuum Chamber Packer

57 Grindder Koch Equipment

58 Butter Churn Coburn Company Milky FJ10 Butter Churn 115V/60HZ
Item Number: 13221 Suggested Retail: $1,571.40

59 Cream Separator Coburn Equipment
Milky Electric Cream Separator L / Hr Item Number: 17584 Suggested Retail: $2,093.60 Capacity 125 Liters (132 Quarts) per hour. Weight 18 lbs.

60 UHT-HTST Micro-thermics Flex Series UHT-HTST-HVH Utilities: City Water
Cooling Water Steam: 80 PSI (5.6 bar) clean dry steam, 45 kg/hr Electrical: 1Ø, 110/220 volt, 20/10 amp Drainage: standard 1.5-2" drain Dimensions: • Bench Top Height: 38" (.97 M) • Bench Top Depth: 32" (.85 M) • Length: 40.5" (1.03 M) • Height: 68" (1.74 M)

61 Columna de destilación
Armfield UOP3CC 25A Solvent resistant level floor. Either a flame-proofed room or in an area where a 2 metre clear and uninterrupted space on each and every side and above the unit can be maintained and into which no potentially spark producing equipment should be allowed to enter. Cold water supply: 15 litres/min at 2.0bar pressure (min.) Exhaust line to fume cupboard or to safe discharge area outside of laboratory.

62 High Pressure Sterilizer
Avure Technologies Inc.

63 Balanzas NDPGW253e 250g Precision Balance Capacity 250g Readability .001g Platform 140x140mm $739.00  NDAQT g Compact Balance Capacity 2000g Readability 1g Platform Size 130mm $99.00

64 Incubadoras Fisher Isotemp* Standard Lab Incubators 30° to 75°C (86° to 167°F) range Incubators with gravity flow circulation Electrical receptacle inside (5A at 120VAC) to plug in a stirrer, shaker, or other apparatus. ....more Includes: Small (2.5 cu. ft.) and medium (3.75 cu. ft.) incubators each come with one plated-steel shelf; large (5.0 cu. ft.) incubator comes with two shelves.

65 BAX System Q7 Innovative PCR technology from Applied Biosystems
BAX® System Q7 offers advanced DNA-based detection for a broad range of sampling applications Although the BAX® system Q7 is completely compatible with currently available assays Flexibility to provide for multiple target detection in the same well, quantitation and species differentiation. Allows you to test multiple targets in the same run, up to 96 samples per batch.

66 Microscope Konus Campus 1000x Biological Microscope
360° revolving binocular head and inter-pupillary distance regulation Two 10x WF eyepieces and four achromatic objectives: 4x, 10x, 40x, 100x Double focusing regulation Light intensity regulation.

67 Spiral Plate Rapid Bacterial enumeration without intermediate dilutions. Automatic sample taking, disinfecting and rinsing. 250 ul of sample drawn in one cycle for plating. Multiple replicate plates prepared consecutively without take up of additional sample. Operating modes: automatic, semi automatic or manual. Plating modes: standard exponential, slow exponential, proportional, uniform and lawn. Continuous supply of disinfecting liquids Bacterial enumeration up to 4,000,000 cfu/ml on 150 mm Petri dishes

68 Colony Counter Boeco Model CC-1 Colony Counter
Latest electronic type ring-shaped lamp used for its illuminating device. Number of counts up to 4 digits and displayed on bright red, 0.6" LED Adjustable focusing arm accommodates lenses of various magnitudes Intelligent counting technology neables the CC-1 to count with any type of marking pen. Accepts 10 to 15 cm. diameter petri dishes using flexible adjuster Zero reset button The background plate can be changed to white or black for easy counting

69 Shaker Incubator New Brunswick Innova 4000 benchtop shaker incubator
Agitation rpm, ±1 rpm Temperature Range: 5°C above ambient (or coolant) to 60°C, and to 80°C in high- temperature Model 4080. Uniform Temperature Control Added Safety Features Interchangeable, Large-Capacity Accessory Platforms, 18" x 18" (46 x 46 cm), accept gel trays, culture tubes and flasks to 2.8 L; snap in place without tools, using optional Quick Change Platform Optional 5-Port Gassing Manifold enables direct gassing into flasks for anaerobic cultures

70 Lab. frezzer Capacities from 23.1 to 74.0 cu. ft. (654 to 2096L)
With or without factory-installed recorders and alarms Adjustable temperatures between -40° and -18°C on L series models, between -29° and -18°C on all others Average temperature stability: ±3°C Display resolution 0.1° CFC-free refrigerant and insulation Automatic defrost

71 Ultra Freezer Capacities from 6.8 to 24.4 cu. ft. (193 to 691L)
1 in. dia. (2.5cm) access port for adding instrumentation to cabinet interior Heavy-duty casters for mobility Reusable air filters "Clean filter" indicator advises when to clean condenser intake filter Digital display of actual alarm battery standby capacity advises when to replace battery

72 Sterilizers Capacity, 3 cu. ft.
Operating pressure: 15psi (1 atm/100kPa) Front-mounted controls with 60-minute timer Fast preheating Doors lock automatically and cannot be opened until pressure is exhausted Incorporate low-water cutoffs, safety valves Release pressure and shut off power supply at end of cycle Polished stainless-steel exterior with adjustable feet Clad aluminum interior chamber

73 Gabinetes Stak-a-Cab Combination Cabinet
Combination corrosives/flammables cabinet Corrosives compartment capacity: 10 x 2.5L (approximately 61/2 gal./25L) Flammables compartment capacity: 8 x 1 gal. (approximately 30L) Gray finish
